It can be found in the "Neighbor" group of select other tools. New select other option to chain select tangent contiguous edges. The dialog warns the user that a copy is being made and objects Inventor Fusion does not support will be removed. Improved import of SolidWorks files that contain configurationsĪ warning is displayed when an AutoCAD DWG file is opened. You can turn on/off the display of features in the browser. When an object is selected, the parents are highlighted in the browser. The section view is dynamically previewed while you drag the section plane. The Slice Graphics command is replaced with the Section command. To access this option, go to the Application Menu and click the Options button. This options is available at View > User Interface > Alternate Zoom Direction. Option to enable alternate zoom direction (allows Fusion to zoom like AutoCAD). This option is available at View > Visual Styles > Effects > Adaptive Performance. Option to disable dropping of visual effects during modeling and view navigation.
#Autodesk inventor 2013 tutorial free#
There is an "Exit Free Orbit" context menu item when the Orbit command is active. New Autodesk Simulation WS product line add-ins. Inventor displays a dialog before launching Edit Form in Fusion. The AutoCAD add-in allows users to edit blocks created by opening Fusion DWG files or DWG files with 3D data in blocks resulting from AutoCAD's native 3D translators. The AutoCAD add-in offers an accept or deny dialog on return to AutoCAD. The AutoCAD add-in and the Inventor add-in will use the open Fusion session. The work axis is created through the center of the circular edge.Ī linear edge can be selected when creating a work plane by point and axis. There is an option to keep the interfering volumes as new components.Ī circular edge can be used to create a work axis. New Interference command displays the interferences between selected components or the entire assembly. You can insert a Fusion DWG into another Fusion DWG and maintain the hierarchy this does not create a link or x-ref to the original DWG. This point-to-point workflow is similar to the AutoCAD move command. When using the Move command to position components, you can reorient the triad to a vertex then move the component to other component vertices. You can turn on/off the preview in the Simplify command. New Fluid Volume command creates internal volumes or external volumes around existing model. New Planarize Edge command aligns the selected edge to a selected plane.Īny edge can be selected to create a surface patch. New Insert Edge command allows you to insert an edge into an existing face. The edges of surfaces can be used with the Assign Symmetry command. Split command allows you to select solid faces as the split tool.Įdit Edge command allows you to G2 Blend or Combine two edges. Split command uses the selected object to automatically determine whether you are splitting a face or a body. Shell a solid without selecting a face to remove. Sweep profiles and the path can be from different components. You can revolve about an axis that is selected as part of the profile. Mirror and pattern support the creation of new components. Shift-select allows window select of profiles.Ĭontextual command menu for selected sketch objects. Simplified sketch grid contextual glyph menu.ĭragging multiple sketch objects now will snap to other sketch points. Spline does not terminate when an existing sketch point is selected.Ĭlick and drag a sketch circle to resize it.
#Autodesk inventor 2013 tutorial generator#
End treatment support on curved frame generator beams.Alignment of a frame member through geometry.Remove internal voids for derived components.Window select area when selecting a hole center.
